The Pitacs 6241B Single Core & Earth LSZH Cable is a high performance Low Smoke Zero Halogen wiring cable designed for fixed electrical installations where enhanced fire safety and reduced smoke emissions are required. Ideal for domestic, commercial and public building applications, this cable is commonly used for lighting circuits, general power wiring and installations in enclosed environments where occupant safety is a priority.
Manufactured with solid copper conductors, cross-linked polyethylene insulation and an LSZH outer sheath, the Pitacs 6241B cable delivers reliable electrical performance alongside improved fire characteristics. In the event of a fire, the LSZH construction helps minimise smoke density and corrosive gas emissions, making it particularly suitable for use in apartment blocks, public buildings, schools, hospitals and escape routes. Manufactured to BS 7211:2012 standards and BASEC approved, this cable provides a dependable and compliant solution for modern fixed wiring installations.
Key Features
Single Core & Earth Low Smoke Zero Halogen cable
LSZH construction for enhanced fire safety
Solid copper conductor for reliable conductivity
Cross-linked polyethylene insulation
Suitable for lighting and small power circuits
Designed for domestic and commercial fixed wiring
Reduced smoke and corrosive gas emissions during fire conditions
Suitable for dry and damp environments
Flat cable profile for tidy installation
Rated voltage: 300/500V
Manufactured to BS 7211:2012 standards
BASEC approved
CE and UKCA certified
Enhanced Safety for Modern Installations
The Pitacs 6241B Single Core & Earth LSZH Cable is designed for installations where limiting smoke and harmful gas emissions is essential. Its LSZH outer sheath and insulation help improve safety in the event of a fire, supporting safer evacuation conditions and reducing potential damage to sensitive equipment.
The cable is suitable for clipping direct to surfaces, installation within conduit and trunking systems, or embedding within suitable building structures where mechanical protection is provided. Its solid copper conductor ensures dependable conductivity and long term reliability for professional electrical installations.
Technical Information
Voltage Rating: 300/500V
Conductor Material: Copper
Conductor Type: Solid Copper
Conductor Class: Class 1
Insulation Material: XLPE
Outer Sheath Material: LSZH
Cable Profile: Flat
Operating Temperature: -15°C to +90°C
Maximum Short Circuit Temperature: 250°C
Minimum Bending Radius: 8 x cable diameter
Suitable for indoor fixed installations
Suitable for dry and damp conditions
Additional Technical Details
Standards: BS 7211:2012 / BS EN 60228
Certifications: BASEC, CE, ISO 9001, UKCA
Flame Retardancy: BS EN/IEC 60332-1
Halogen Free: IEC/EN 60754-1/2
Smoke Emission Standard: EN 61034
Core Configuration: Single insulated conductor with earth conductor
Outer sheath colour: White
Inner core colour: Brown
Available sizes include 1.0mm² and 1.5mm²
Supplied in coils and drums depending on cable size and length
Current carrying capacities vary depending on installation method and cable size
What’s in the Box
Pitacs 6241B Single Core & Earth LSZH Cable coil or drum
The Pitacs 6241B Single Core & Earth LSZH Cable provides a professional grade fixed wiring solution combining dependable electrical performance, enhanced fire safety properties and compliance with UK wiring standards, making it ideal for modern domestic and commercial installations.
