Pitacs Flexi Meter Tail Pack 25mm² x 3m: 6181Y Double Insulated Flexi 19 Stranded (Brown with Brown) and (Blue with Blue) plus 6491X Single Core (Green/Yellow)

Pitacs Flexi Meter Tail Pack 25mm² x 3m – 6181Y Double Insulated Flexi 19 Stranded and 6491X Single Core Earth Cable

The Pitacs Flexi Meter Tail Pack 25mm² x 3m provides a professional and convenient solution for electrical meter and consumer unit installations where enhanced flexibility and reliable performance are essential. Supplied with 3 metre lengths of Pitacs 6181Y Double Insulated Flexi 19 Stranded Cable in Brown with Brown and Blue with Blue, together with a 6491X Green/Yellow Single Core Earth Cable, this complete pack is ideal for domestic and light commercial fixed wiring applications.

Manufactured using fine stranded copper conductors with durable PVC insulation and sheathing, the Pitacs Flexi Meter Tail Pack offers greater flexibility than standard meter tails, making installation easier in confined spaces and around tighter bends. The included double insulated flexi tails are designed for fixed wiring connections between electricity meters and consumer units, while the green/yellow earth cable provides a dependable protective earthing connection. Manufactured to recognised UK standards and BASEC approved, this pack provides a trusted and compliant solution for modern electrical installations.

Key Features

• Complete 25mm² flexi meter tail pack
• Includes Brown and Blue double insulated flexi meter tails
• Supplied with Green/Yellow earth cable
• 19 stranded flexible copper conductors for easier installation
• 3 metre cable lengths for standard installations
• Suitable for domestic and light commercial applications
• Improved flexibility for routing in confined spaces
• Durable PVC insulation and sheathing
• Ideal for consumer unit and meter connections
• Suitable for fixed wiring installations
• Manufactured to relevant UK standards
• BASEC approved
• CE and UKCA certified

Enhanced Flexibility for Easier Cable Routing

The Pitacs Flexi Meter Tail Pack is designed to simplify installations where flexible cable routing is beneficial. The 19 stranded copper conductor construction provides improved manoeuvrability compared to conventional meter tails, helping electricians install cables more efficiently around bends and within compact consumer unit spaces.

The included 6491X Green/Yellow single core earth cable delivers a reliable and compliant earthing solution suitable for modern consumer unit and distribution board installations. Ideal for new installations, consumer unit upgrades and replacement projects, this complete flexi meter tail pack combines flexibility, convenience and dependable electrical performance.

Technical Information

• Cable Size: 25mm²
• Tail Length: 3m each
• Voltage Rating: 300/500V
• Conductor Material: Copper
• Conductor Type: 19 Stranded Flexible Copper
• Insulation Material: PVC
• Outer Sheath Material: PVC
• Operating Temperature: -15°C to +70°C
• Maximum Short Circuit Temperature: 160°C
• Suitable for indoor fixed installations
• Suitable for dry indoor environments

Additional Technical Details

• Included Cables:
  • 1 x 3m 25mm² Pitacs 6181Y Double Insulated Flexi 19 Stranded Cable – Brown with Brown
  • 1 x 3m 25mm² Pitacs 6181Y Double Insulated Flexi 19 Stranded Cable – Blue with Blue
  • 1 x 3m 25mm² Pitacs 6491X Single Core Cable – Green/Yellow
• Standards: BS 6004 / BS EN 50525
• Certifications: BASEC, CE, ISO 9001, UKCA
• Application: Meter tails and earthing connections
• Suitable for consumer units and distribution boards
• Current carrying capacities vary depending on installation method

What’s in the Box

• 1 x 3m 25mm² Pitacs 6181Y Double Insulated Flexi 19 Stranded Cable – Brown with Brown
• 1 x 3m 25mm² Pitacs 6181Y Double Insulated Flexi 19 Stranded Cable – Blue with Blue
• 1 x 3m 25mm² Pitacs 6491X Single Core Cable – Green/Yellow

The Pitacs Flexi Meter Tail Pack 25mm² x 3m offers a dependable and professional wiring solution for electrical installations, combining enhanced cable flexibility, durable insulation and trusted UK standard compliance for reliable consumer unit and meter connections.
